Automatic  Shaft Straightening Machine

The servo motor drives the workpiece to rotate, and the measurement and control system collects the displacement sensor data of the measuring point and straightens the measuring point in real time.

The workpiece rotation motor drives the workpiece to rotate to the alignment position, where the high point is facing upwards and waits for straightening. In the process of positioning, forward and reverse rotation control can be realized, and the nearest high point can be stopped.

Equipped with a variety of sensors, such as laser displacement sensors and contact - type displacement sensors. These sensors can accurately measure the shape of the workpiece in real - time during the straightening process. The laser displacement sensor works by emitting a laser beam and receiving the reflected light to calculate the position of the workpiece's surface points, thereby obtaining a detailed shape profile of the workpiece.

Click to straighten the video
