automatic tube straightening machine

Measurement method: mechanical lever amplification, real-time contact, tracking and measurement mode.

(The measurement part consists of the displacement sensor, the measuring head, and the lever mechanism.

The measuring head is mounted at the front end of the lever, and the displacement sensor measures the head at the back end of the lever.

When measuring head in the reset spring under the action of the lower surface, the rotating beat by the measuring head real-time tracking and

beat through the lever to the displacement sensor, the computer with a certain sampling frequency data acquisition of each sensor, so that the

measurement section beating value coordinate system, achieve high positioning).
